COVID-19 alert system

Published Jul 24, 2020
 5 hours to build
 Intermediate

Avoiding the entry of people with COVID-19 symptoms. This proposed mechanical setup allows or denies the entry of the people with respect to their medical condition tested by our IOT supported mechanical setup.

display image

Components Used

Ultrasonic Module HC-SR04
Ultrasonic module HC-SR04 is generally used for finding distance value and obstacle detection. It can operate in the range 2cm-400cm.
2
NodeMCU
NodeMCUNodeMCU
1
Description

When this prototype is installed in any type of entry point, it will check for the Corona infection symptoms. Fever and cough symptoms will be monitored and reports will be generated in the cloud. If the symptom test results are positive, the respective person shall not be allowed to enter the place. Adding more, the report regarding the positive symptoms will also be sent to their family through the mail for precaution. The further process can be taken to isolating the person. Thus achieving the maximum control of the spreading of this deadly infection. This prototype can be installed in all possible public places such as schools, colleges, offices, stores/shops, hospitals, etc,.

Circuit Connection

Ref: circuit Digest

We have used Node MCU as the micro-controller here, with DHT11 - temperature sensor and Ultrasonic sensor for measuring proximity of the person and RFID sensor for gathering his/her details.

Codes

Downloads

Circuit Diagram model Download
