Design and Implementation of Car Blackbox System

Published May 27, 2026
 60 hours to build
 Advanced

Designing a car black box to prevent driver safety and it helps response quickly. It will helps avoid deaths by road accident and helps in investigation

display image

Components Used

ESP32 DevKitC 32E
ESP32 DevKitC 32E
1
MPU6050 Gyroscope and Accelerometer
MPU6050 (Gyroscope + Accelerometer + Temperature) is a combination of 3-axis Gyroscope, 3-axis Accelerometer and Temperature sensor with on-chip Digital Motion Processor (DMP). It is used in mobile devices, motion enabled games, 3D mice, Gesture (motion command) technology etc
1
LM2596 Adjustable Buck Converter
Power Management IC Development Tools LM2596ADJ TO220 BUCK DB
1
SD Card Module
SD Card
1
GPS Neo-6m GPS Module
This is a complete GPS module that is based on the NEO 6M GPS. This unit uses the latest technology to give the best possible positioning information and includes a larger built-in 25 x 25mm active GPS antenna with a UART TTL socket. A battery is also included so that you can obtain a GPS lock faster. This is an updated GPS module that can be used with ardupilot mega v2. This GPS module gives the
1
GSM SIM 800L module
gsm sim 800l is a 2G sim module used for messaging, it could be replace with SIM 900A
1
CAN module
1
LCD Display (16x2 I2C)
Displays live system status and sensor readings.
1
Description

I have gathered the required libraries and created a development plan for where to begin. Now, I need to:

1. List and define all functions, features, and operations of the module.



2. Understand and document the complete working methodology of the module.



3. Begin development by integrating each component step-by-step.



4. Verify communication and interaction between all integrated components.



5. Refine, optimize, and improve the module for better performance, reliability, and scalability.



6. Continuously test and debug the system during each development stage.



7. Finalize the module with a clean architecture, proper documentation, and production-ready implementation.
