Smart Banking Machine System with fingerprint and Iris recognition

Published Dec 16, 2020
 25 hours to build
 Intermediate

The Smart Banking Machine can be secure by using Fingerprint and Iris recognition for users. Inspite of using ATM card and pin number ,The user can recognise their Fingerprint and Iris Biometric to avoid from hackers by GSM Technology and OTP received by user's mobile number. It is very much useful .

display image

Components Used

Relay Module Two channel
Relay Module Two-channel
1
LCD16x2 Display
LCD16x2 Display
1
PIC16f877a
PIC16f877a
1
Tilt Sensor - AT407
Tilt Sensor - AT407
1
Buzzer 5V
Buzzer 5V
1
Fingerprint Sensor Modules
Fingerprint Sensor Modules
1
BC547 TRANSISTORS
BC547 TRANSISTORS
1
Resistor 1 Ohms
Metal Film Resistors - Through Hole 1 OHM 1/4W 1%
1
Capacitor 100nF
Multilayer Ceramic Capacitors MLCC - Leaded K 50V 100NF +/- 10 % X7R AMMO E3
1
DC Gearbox Motor
Adafruit Accessories DC Gearbox Motor - TT Motor - 200RPM - 3 to 6VDC
1
12V SMPS
Switching Power Supplies AC-DC 35W LOW COST
1
Description

When user uses the ATM machine ,first he /shechecks his /her fingerprint. When it matches ,then verify his/her iris and face recognition. When it matches their account ,they can able to use that account number easily without hacking. When it verified successful,OTP received to registered mobile number and check it and take the withdrawal or transaction processes.

Downloads

Fig-5-1 Download
design-of-a-wireless-medical-monitoring-system-5880-wlqkWV0 Download

Institute / Organization

BANNARI AMMAN INSTITUTE OF TECHNOLOGY, SATHYAMANGALAM
